Trailer Asphalt Distributor
Detail Information
Main Technical Description
Asphalt distributor s special machinery for construction of asphalt pavement newly developed by our company. It can be widely used in spraying of high-temperature liquid asphalt and emulsified asphalt. The machine has turning system and brake system (all the other similar products in China are not equipped with turning and brake system), so that the machine operates stably, safely and reliably. Manual sprayer nozzle and post automatic spraying are adopted. At the same time it is equipped with high power gasoline generator . This equipment is beautiful and decent. The structure is compact. It is mobile and flexible. The center of gravity is relatively low. It is convenient to use and suitable for repairing, pavement maintenance and other operation.
Main Technical Parameter
Model |
ZM-10(Just hand spray) | ZMTS-10 |
ZMTS-25 |
ZMTS-30 |
ZMTS-30(with hydraulic system) |
Dimension(mm) |
3460×1820×1800 | 4960×2000×2100 |
4960×1860×2450 |
4960×1860×2500 |
5900×2100×2560 |
Lane way |
Trailer |
||||
Brake mode | Use oil for brake | ||||
Turning way | Connecting bar | ||||
Engine | Changchai 9Kw | Changchai 11Kw diesel engine | JD 20KW | ||
Tank capacity(L) | 1000 | 1000 | 2500 | 3000 | 3000 |
Spraying width(m) | / | 2 | 2 | 2 | 4.5 |
Hand spray | 5m spray lance with special nozzle | ||||
Spray Value(kg) | 0.5-3.0 | ||||
Nozzle | / | 15 | 15 | 15 | 35 |
Engine power(kw) | 5.67 | 20 | |||
burner | G10（Riello）-Italy automatic diesel burner | ||||
Product pictures
Imported engine
Integrated control panel
Generator with water cooled engine
One key open and closed nozzles
